Description SPEED-X 9600 2D DESKTOP BARCODE SCANNER – Detail: 2D Barcode Image Scanner Technical Specifications Electrical Characteristics Interface Supported USB HID KEYBOARD/USB VCP Input Voltage DC 5V±5% Current Max:335mA Optical Characteristics Image Sensor CMOS Array Sensor Sensor Resolution 640 X 480 Pixels Light Source white LED Decoding speed 60FPS Performance Characteristics Scanning Angle Pitch angle:±65°;Skew angle:±65°;Tilt angle:±360° Field of View 36H),27V) Min Resolution 4mil Min .PCS value 〉20% UPC/EAN 13（13mil） Language Multiple Languages Data Edition Support for custom data output Decode Capability 1D:Codabar,Code39,Interleaved2of5,NEC2of5,Code93 ,Straight 2 of 5 Industial,Straight 2 of 5 IATA ,Matrix 2 of 5 ,Code 11,Code128,GS1-128,UPC-A,UPC-E0,UPC-E1,EAN/JAN-13,EAN/JAN-8,MSI,GS1-DataBar Omnidirectional,GS1 DataBar Limited,GS1 DataBar Expanded , China Post(Hong Kong 2 of 5),GS1 Composite Codes,Codeblock A,Codeblock F,Code 32,EAN/JAN-8,Korea Post 2D：PDF417,QR Code,Data Matrix,Aztec code,HanXin code,MaxiCodeMaxi code,Micro PDF417 Physical Characteristics Dimensions 94mm*100mm*152mm(L*W*H) Weight 260g Indicator Beeper, LED Environmental Characteristics Temperature -20°∽60°C (operation) -30°∽70°C (storage) Humidity Relative humidity: 5% to 95% (no condensation) Shock Drop Test 1.5m drop onto concrete surface Decoding Depth of Field Symbology Resolution Nearest Farthest Code 39 5mil 10mm 90mm Code 39 13mil 0mm 175mm UPC-A 3.34mil 10mm 170mm QR 20mil 0mm 130mm QR 30mil 0mm 180mm Pay Code（QR 3*3cm） – 10mm 320mm Pay Code（QR 2.3*2.3cm） – 0mm 260mm Weight: 1.00 KGs
