Description SPEED-X 60D 2D Wirless 2.4Ghz barcode scanner With Stand – Detail: (2D CMOS Wireless 2.4G Handheld Barcode Scanner) Technical Parameters Wireless specifications Communications 2.4GHz Communication frequency 2.402 to 2.480GHz Transmission range ≤30M（In empty area 30M ） Data rate 1Mbps Memory 100000@13Byte barcode Battery capacity 1500mAh (Lithium battery) Charging time 4.5H The life time of the full charge 4h（continuous reading situation） 9.5h（Manual reading situation） More than 15 days （Stand-by time) Communication mode Read-time mode/Inventory mode Electrical Characteristics Interface USB HID KEYBOARD（Wireless receiver） Voltage requirement Max:120mA Min：50mA Optical Characteristics Photo sensor CMOS array sensor SENSOR RESOLUTION 648 X 488 Pixels Light source White LED Aim light source Red Bar LED Performance Characteristics Decode angle Pitch angle:±60°;Skew angle:±60°;Tilt angle:±180° Min resolution 1D≥4mil 2D≥10mil Min.PCS value 〉15% UPC/EAN 13（13mil） Field of View 46°(H),35°(V) Identification 1D： Codabar，Code128，Code11，Code32，Code39，Code93，Composite，EAN/UPC,EAN-8,EAN-13,GS1 DataBar Expanded，GS1 DataBar Limited，GS1 DataBar Omnidirectional，Hong Kong 2 of 5（China Post），Interleaved 2 of 5，Matrix 2 of 5 Pharmacode. RSS-14,RSS-LIMITED, RSS-EXPANDED, Industrial 2 of 5,Telepen,Trioptic Code, UPC-A,UPC-E 2D：Aztec Code，Codablock F，DOT_CODE, HANXIN, Maxicode，MicroPDF417，Micro QR Code，MSI，PDF417,QR Code, DataMatrix Physical Characteristics Dimensions Scanner：95mm×70mm×168mm（L x W x H） Receiver：83mm*18mm*13mm(L*W*H) Weight Scanner：186g Receiver：16g Environmental Characteristics Temp 0°∽50°C / 32°∽122°F(operation) /-10°∽60°C /14°∽140°F(storage) Humidity 20 – 85% (operation) ) 20 – 95% (storage) Shock drop test 1.5m drop onto concrete surface Ambient Light: fluorescent light 4000 lx max , direct sun light 80,000 lx max ,white light 4000 lx max Decoding Depth of Field Symbology Resolution Nearest Farthest Code 39 20mil 5.5cm 35cm Code 128 15mil 6cm 31cm EAN-13 13.34mi 6cm 25cm QR code 20mil 4cm 21cm PDF417 13.34mil 3cm 29cm Weight: 0.50 KGs
